Teknisk data:

Operating voltage: 12-45Vdc
Idle current: approx. 25mA (enable “0”)
Current set: 0.5; 1,0; 1.5; 2.0; 2.5; 3.0; 3,5 and 4.0A
Voltage loss: 1V when Im=1A
Fuse: 4A self recovery.
Aux. osc. freq: 200, 500, 1000, 2000 Hz 3000, 5000, 8000 Hz
Ramp speed: 0,2…3s (0…8000 Hz)
Aux. freq. precision: better than 0,5%
Digital control: “on” when Uin 4 -30V “off” when Uin 0-1V
Step freq. max: 15 kHz
Operating temp: 0-50°C
Dimensions: 87x73x35mm
Weight approx: 90g
